Some time ago I was developing a medical instrument which required histogramming, which got me in the mood to retake my own PIC MCA project(http://home.comcast.net/~prutchi/index_files/scint.htm ). I used the variable RAM in the microcontroller (16F877), so I limited the number of channels to 95 and let the histogram run until some channel reaches 240 counts (the highest 8-bit number that yields an integer when divided by 8). The firmware then displays the spectrum as a bar with a maximum height of 30 pixels for each one of the 95 channels.
Click here for complete how-to construction instructions in pdf format.
Click here for a pdf of the schematic diagram for the front-end of the MCA






Lately I’ve received many inquiries about the paper on radiation-hardness testing of implantable integrated circuits that I published with Dr. Larry Stotts (now Executive VP R&D at Biotronik), and the late Dr. John Prince. This is because the effects of medical diagnostic and therapeutic radiation are becoming an issue of concern to physicians who often encounter the need for radiotherapy in the growing population of patients implanted with pacemakers, defibrillators, neural stimulators, and drug-delivery pumps.
