A Custom Base for using the EMI/Thorn 9816B Photomultiplier Tube with the Products for Research Model TE-182 Thermoelectrically-Cooled PMT Housing for Ultra-Low Light Level Experiments

Posted on by Posted in David, Quantum Physics

For a detailed writeup in pdf format please CLICK HERE

I’ve been planning some experiments with single-photon and ultra-low light levels. For these experiments I want the collection area to be large and for the detector to have very broad spectral response, so my preference is to use a photomultiplier tube (PMT) instead of a “silicon photomultiplier” avalanche single-photon detector.

I found a brand new EMI 9816B PMT on eBay® which meets my requirements. The 9816B is a 51 mm (2”) diameter end-window photomultiplier, with an S20 infrared-sensitive photocathode, and 14 BeCu dynodes of linear focused design. This tube features a very high gain of 25×106 A/lm under nominal conditions (2,200V) with a quantum efficiency of 21% at the peak response wavelength.

Integration time, and ultimately resolution and sensitivity for detecting single-photons or ultra-weak light levels are dependent on the noise floor (dark counts) which is a function of temperature. Cooling the PMT dramatically reduces its dark current and counts.

I bought a surplus thermoelectrically-cooled housing by Products for Research (Model TE-182) which is made for 2” end-window PMTs. I could not find a surplus base for the EMI 9816B 14-dynode PMT, so I decided to buy a surplus base for a different tube and modify it for the 9816B.

Products for Research TE-182 Thermoelectrically-Cooled Housing for 2″ PMTs

Clearing the inside of the base was a very messy affair. This is because the dynode voltage divider chain is partially potted in silicone, and the rest of the base is filled with expanding thermal-isolation foam. Part of the base is made of plastic, so the use of harsh chemical solvents or heat to remove the silicone rubber and expanding foam were not possible. I thus had to use a scalpel and dental picks to remove all this insulation and be able to disassemble the tube socket.

I built a new divider on a piece of phenolic breadboard . The base is wired for high voltage (-2,300V) applied to the cathode (through a 33k? resistor). The dynode_1-to-dynode_14 divider is built with 330k? resistors. As suggested by EMI, the cathode-to-focus (and dynode_1) is set at a fixed 300V difference using two 150V Zener diodes in series.

Results from a characterization run are shown in the following table. The room-temperature dark current agrees with the specified value. A very dramatic drop in dark current and dark count rate can be observed when the PMT is cooled.

For a detailed writeup in pdf format please CLICK HERE

Febetron/Fexitron High-Voltage 2-Stage Marx Generator Module

Posted on by Posted in David, High Voltage

I have kept on making space in my lab for new projects, and came across 3 new-old-stock Marx generator modules that were made for the Fexitron and Febetron flash X-ray sources and electron accelerators.  The Fexitron and Febetron devices were made in the 1970s by the Field Emission Corporation, a division of HP, which is now L-3 Pulse Sciences.

Each module contains two complete 30 kV Marx stages.  In the Febetron/Fexitron pulsers, modules were stacked to form Marx generators of up to 2.3MV output. The spark gap distance is adjustable. These modules are designed for use under 20-70 psi air or nitrogen.

My intention was to build a 180 kV fast Marx with these, so I had reverse-engineered the schematic for these modules.  I’m putting it here in case that someone is interested.

The following are interesting links related to Fexitron/Febetron units:
